USK Submersible Pump 4SDM318 1.5HP
Original price was: KSh 20,000.00.KSh 15,500.00Current price is: KSh 15,500.00.
The 1$\text{USK Submersible Pump 4SDM318}$ is a high-performance, multi-stage, deep-well submersible pump with a 2$\mathbf{1.5\text{ HP}}$ motor, suitable for drawing water from significant depths.3
The model number $\text{4SDM318}$ provides the following details:
- 4: 4$\mathbf{4\text{ inch}}$ pump diameter (designed for 5$4\text{ inch}$ and larger boreholes).6
- SDM: Standard Submersible Deep Well Pump with a Single-Phase Motor.
- 3: Represents the approximate rated flow rate series (e.g., $3 \text{ m}^3\text{/h}$).
- 18: Indicates the number of impellers or stages. This high number of stages is what allows the pump to achieve its impressive maximum head.
Key Technical Specifications
For the USK 7$\text{4SDM318}$ model with a 8$\mathbf{1.5\text{ HP}}$ motor (9$\text{1.1 \text{ kW}}$):10
| Feature | Typical Specification |
| Model | $\text{4SDM318}$ (or $\text{4SDM3/18}$) |
| Pump Type | Multi-Stage Centrifugal Submersible |
| Motor Power | $\mathbf{1.5\text{ HP}}$ ($\text{1.1 \text{ kW}}$) |
| Casing Diameter | $\mathbf{4\text{ inch}}$ |
| Max Head (Lift Height) | $\text{Approx. } 125 \text{ m}$ to $\mathbf{129\text{ m}}$ (meters) |
| Rated Flow Rate | $\text{Approx. } 3 \text{ m}^3\text{/h}$ ($\text{50 \text{ L/min}}$) at $\sim 90 \text{ m}$ head |
| Max Flow Rate | Up to $\text{4.8 \text{ m}^3\text{/h}}$ ($\text{80 \text{ L/min}}$) at low head |
| Number of Stages | $\mathbf{18}$ |
The 1$\text{USK Submersible Pump 4SDM318}$ is a high-performance, multi-stage, deep-well submersible pump with a 2$\mathbf{1.5\text{ HP}}$ motor, suitable for drawing water from significant depths.3
The model number $\text{4SDM318}$ provides the following details:
- 4: 4$\mathbf{4\text{ inch}}$ pump diameter (designed for 5$4\text{ inch}$ and larger boreholes).6
- SDM: Standard Submersible Deep Well Pump with a Single-Phase Motor.
- 3: Represents the approximate rated flow rate series (e.g., $3 \text{ m}^3\text{/h}$).
- 18: Indicates the number of impellers or stages. This high number of stages is what allows the pump to achieve its impressive maximum head.
Key Technical Specifications
For the USK 7$\text{4SDM318}$ model with a 8$\mathbf{1.5\text{ HP}}$ motor (9$\text{1.1 \text{ kW}}$):10
| Feature | Typical Specification |
| Model | $\text{4SDM318}$ (or $\text{4SDM3/18}$) |
| Pump Type | Multi-Stage Centrifugal Submersible |
| Motor Power | $\mathbf{1.5\text{ HP}}$ ($\text{1.1 \text{ kW}}$) |
| Casing Diameter | $\mathbf{4\text{ inch}}$ |
| Max Head (Lift Height) | $\text{Approx. } 125 \text{ m}$ to $\mathbf{129\text{ m}}$ (meters) |
| Rated Flow Rate | $\text{Approx. } 3 \text{ m}^3\text{/h}$ ($\text{50 \text{ L/min}}$) at $\sim 90 \text{ m}$ head |
| Max Flow Rate | Up to $\text{4.8 \text{ m}^3\text{/h}}$ ($\text{80 \text{ L/min}}$) at low head |
| Number of Stages | $\mathbf{18}$ |
| Weight | 5 kg |
|---|
