-48%
USK Submersible Pump 4SDM324 2HP
Original price was: KSh 20,000.00.KSh 17,500.00Current price is: KSh 17,500.00.
USK Submersible Pump 3SDM220 0.75HP Slim Pump
Original price was: KSh 20,000.00.KSh 12,500.00Current price is: KSh 12,500.00.
USK Submersible Pump 3SDM214 0.5HP Slim Pump
Original price was: KSh 20,000.00.KSh 10,500.00Current price is: KSh 10,500.00.
The $\text{USK Submersible Pump 3SDM214}$ is a $\mathbf{0.5\text{ HP}}$ single-phase, multi-stage “slim pump” designed for boreholes with a smaller internal diameter.
The model number $\text{3SDM214}$ provides the essential characteristics:
- 3: $\mathbf{3\text{ inch}}$ pump diameter (designed for $3\text{ inch}$ or $80\text{ mm}$ boreholes, which is narrower than the standard $4\text{ inch}$). This is the reason it is referred to as a “Slim Pump.”
- SDM: Standard Submersible Deep Well Pump with a Single-Phase Motor.
- 2: Represents the approximate rated flow rate series (e.g., $2 \text{ m}^3\text{/h}$).
- 14: This number indicates the number of impellers or stages in the pump, which determines its maximum lift capability.
Estimated Key Technical Specifications
The $\text{0.5\text{ HP}}$ motor and $\mathbf{14}$ stages classify this as a high-head, low-flow pump, common for small domestic deep wells.
| Feature | Typical Specification |
| Model | $\text{3SDM214}$ |
| Pump Type | Multi-Stage Centrifugal Submersible “Slim Pump” |
| Motor Power | $\mathbf{0.5\text{ HP}}$ ($\text{0.37 \text{ kW}}$) |
| Casing Diameter | $\mathbf{3\text{ inch}}$ ($\text{75 \text{ mm}}$ to $\text{76 \text{ mm}}$) |
| Max Head (Lift Height) | $\text{Approx. } 80 \text{ m}$ to $\mathbf{90\text{ m}}$ (meters) |
| Rated Flow Rate | $\text{Approx. } 2 \text{ m}^3\text{/h}$ ($\text{33 \text{ L/min}}$) |
| Max Flow Rate | Up to $\text{3 \text{ m}^3\text{/h}}$ ($\text{50 \text{ L/min}}$) at low head |
| Number of Stages | $\mathbf{14}$ |
Description
The $\text{USK Submersible Pump 3SDM214}$ is a $\mathbf{0.5\text{ HP}}$ single-phase, multi-stage “slim pump” designed for boreholes with a smaller internal diameter.
The model number $\text{3SDM214}$ provides the essential characteristics:
- 3: $\mathbf{3\text{ inch}}$ pump diameter (designed for $3\text{ inch}$ or $80\text{ mm}$ boreholes, which is narrower than the standard $4\text{ inch}$). This is the reason it is referred to as a “Slim Pump.”
- SDM: Standard Submersible Deep Well Pump with a Single-Phase Motor.
- 2: Represents the approximate rated flow rate series (e.g., $2 \text{ m}^3\text{/h}$).
- 14: This number indicates the number of impellers or stages in the pump, which determines its maximum lift capability.
Estimated Key Technical Specifications
The $\text{0.5\text{ HP}}$ motor and $\mathbf{14}$ stages classify this as a high-head, low-flow pump, common for small domestic deep wells.
| Feature | Typical Specification |
| Model | $\text{3SDM214}$ |
| Pump Type | Multi-Stage Centrifugal Submersible “Slim Pump” |
| Motor Power | $\mathbf{0.5\text{ HP}}$ ($\text{0.37 \text{ kW}}$) |
| Casing Diameter | $\mathbf{3\text{ inch}}$ ($\text{75 \text{ mm}}$ to $\text{76 \text{ mm}}$) |
| Max Head (Lift Height) | $\text{Approx. } 80 \text{ m}$ to $\mathbf{90\text{ m}}$ (meters) |
| Rated Flow Rate | $\text{Approx. } 2 \text{ m}^3\text{/h}$ ($\text{33 \text{ L/min}}$) |
| Max Flow Rate | Up to $\text{3 \text{ m}^3\text{/h}}$ ($\text{50 \text{ L/min}}$) at low head |
| Number of Stages | $\mathbf{14}$ |
Additional information
| Weight | 3 kg |
|---|
