Aico Japan Brand Hydraulic Pipe Bender SWG-4A 1/2 to 4 inches

Technical Specifications

• Brand/Series: Aico Japan Industrial Series

• Model: SWG-4A

• Maximum Hydraulic Ram Force: 23 to 25 Metric Tons

• Ram Stroke/Travel: Approx. $370\text{–}420\,\text{mm}$

• Bending Range Capacity: $1/2\text{“}$, $3/4\text{“}$, $1\text{“}$, $1\text{–}1/4\text{“}$, $1\text{–}1/2\text{“}$, $2\text{“}$, $2\text{–}1/2\text{“}$, $3\text{“}$, and $4\text{“}$ (Nominal Pipe Size)

• Bending Angle Range: $0^\circ \text{ to } 90^\circ$ maximum per setup position

• Compatible Pipe Wall Thickness: Optimized for standard Schedule 40 and Schedule 80 gas, water, galvanized, and black iron steel pipes ($2.75\,\text{mm}$ to $6.0\,\text{mm}+$ wall thickness)

• Chassis Design: Extended horizontal plate H-frame configuration with reinforced cross-braces, heavy removable support legs, and an integrated dual-speed manual pump handle
